specs
4 IP channels up to 4K / 8MP
Video compression: Smart H.265 +, H.265, Smart H.264 +, H.264
Simultaneous HDMI (4K) and VGA (1080P) video outputs
Output division: 1, 4
1 RCA input / 1 RCA audio output
Two-way audio via RCA input / output
Audio compression: G.711a, G.711u, PCM, G726
Recording resolution: 4K / 8MP, 5MP, 4MP, 3MP, 1080P, 720P, D1, CIF
Bandwidth: 128 Mbps for access, 128 Mbps for storage and 64 Mbps for forwarding
Decoding capacity: 2 channels at 8MP (25 ips), 4 channels at 4MP (25 ips), 4 channels at 1080P (25 ips)
Manual, alarm, motion detection and timed recording modes
Alarm by video sensor, by privacy mask, by video loss, IP camera
4 alarm inputs / 2 outputs
Playback of up to 4 channels
Internal capacity for 2 SATA HDDs up to 10TB (sold separately)
New user interface with a simpler user experience
Supports perimeter protection, SMD Plus and heat map functions of compatible DAHUA cameras
Supports smart search by metadata
Supports ANR (automatic network replenishment technology): In case of network failure, images are recorded on the IP camera's SD card, which are transferred to the NVR once the network is restored
Software and hardware watchdog
Watermark to preserve the integrity of the videos
RJ45 Fast Ethernet network port (10 / 100Mbps)
4 PoE ports (10 / 100Mbps) with an output power of 25.5W per port and a total of 36W
Network protocols: HTTP, HTTPS, TCP / IP, IPv4, RTSP, UDP, NTP, DHCP, DNS, P2P
ONVIF (Profile S), CGI and SDK compliant
Remote access from web browser (IE9, Chrome, Firefox) and iPhone, iPad (iDMSS) and Android (gDMSS) devices
Server Access local network and Internet
Possibility of limiting user access to cameras in local and / or remote mode
Can be remotely controlled by Joystick keyboard connected by TCP / IP
Sending emails with attached photograph in alarm
Send to FTP scheduled or in alarm
Possibility of sending alarm, and being connected to video surveillance receiver software
Possibility of fixed or dynamic IP through Dyndns service, NoIP, DDNS Evolution, etc.
Communication ports: 2 USB 2.0 ports
Power supply: 48V DC / 53V DC, 1.5A / 1.36A (≤10W, not counting discs)
-10 ° C ~ + 55 ° C operating temperature
10% ~ 90% relative humidity
Dimensions: 375 (W) x 53 (H) x 282.4 mm
Weight: 1.58 kg
Desktop installation
